In a fascinating project, Ben has transformed one of his old 3D printers into a robust, state-of-the-art robotic camera rig. The journey began as an attempt to build a photogrammetry rig, and the end result is a testament to creativity and resourcefulness.
Initially, the plan was to spin the camera, but due to its size, it proved challenging. Hence, the final project rotates the object on a turntable instead. This adjustment, however, doesn't compromise the quality of the video the rig captures, as it takes smooth footage and can spin around for photogrammetry.
The heart of the robotic camera rig is a robust, vibration- and shock-resistant camera with lens, provided by a Japanese company. The design files for the parts of the rig, however, were not provided, leading to a blend of 3D printed parts and CNC-milled components.
Numerous 3D printed parts can be found in the robotic camera rig, including motors, lead screws, gears, and belts. Some parts were CNC-milled from metal for both appearance and rigidity. Interestingly, Ben upgraded one stepper motor to one that uses gears, enhancing the rig's performance.
Wire management is another concern in the project, ensuring a clean and organised setup. The extruder motor in the robotic camera rig rotates the target object, while the Y axis moves the camera forward and backward. The camera on the rig tilts plus or minus 90 degrees on the X axis.
Notably, this project is an example of upcycling an old 3D printer, demonstrating the versatility of these machines. It also showcases how technology can be recycled, as some camera rigs, including this one, recycle other technology.
Motion control became mainstream due to the availability of 3D printers, and this project is a clear demonstration of that. The final robotic camera rig rotates the object, not the camera, providing a stable platform for capturing high-quality images and videos.
In conclusion, Ben's upcycled robotic camera rig is a remarkable example of innovation and resourcefulness. It serves as a reminder that with a little creativity and the right tools, old technology can be given new life.
