Radar's Invention Journey: Significant Milestones, Pivotal Discoveries, and Game-Changing Tech Advancements
Rebooting History's Titan: The Chain Home Radar and Its Unyielding Prowess
June 6, 2024 will mark the 80th anniversary of the D-Day landings, a historical event that altered the course of World War II. In honor of this momentous occasion, we delve into the influential technology that played a crucial role in this battle - radar.
In a recent issue of How It Works magazine, we shed light on one of the most significant pieces of technology that contributed to the Allied forces' victory in World War II - radar.
One of the most influential moments in radar's history was the conception of an early warning system in Great Britain, under the codename 'Chain Home.' With concerns regarding the incorporation of 'death-ray' radio technology on German fighter planes in a potential second world war, Britain gravely responded by erecting coastal radar stations to spot aircraft before they breached its borders. Chain Home was a network of transmitter antennae and receiver stations, forming a gigantic radar system that could detect incoming aircraft from approximately 100 miles away. An observation would appear on a radar display, alerting the operator of the aircraft's presence. This provided the Royal Air Force with around 20 minutes to mobilize and engage the enemy before they reached land. By 1939, Britain already had 18 Chain Home radar stations, with 53 being constructed by the end of World War II.
Chain Home also paved the way for the development of new radar devices with increased ranges. The catalyst? The cavity magnetron, a pioneering technology that employs microwaves to detect fighter aircraft and military sea vessels.
Speaking with BAE Systems, Murray Niman, the senior radar and antennae engineer, illuminates the impact early radar had, not only on winning World War II but on advancing science:
Q: How precisely could Chain Home radar locate moving aircrafts?
A: A typical CH (Chain Home) site would encompass several acres, comprising a transmitter site with three or four steel towers, standing 360 feet tall, and a receiver site with four towers, measuring 240 feet. These towers supported the antenna systems. The transmitter array floodlit the area in front of it, and the receiver used radio direction finding techniques to determine the target's position and altitude. Initially, the CH system could establish accurate bearings, with ranges generally within 5 miles, though this improved over time.
Q: What were the biggest advantages of Chain Home radar to Britain’s air defense?
A: During the battle of Britain, CH enabled our limited number of fighter aircraft to get to the right location at the right time while minimizing fuel usage. This actuated as a significant 'force multiplier.' Historians now agree that CH played an essential role in winning the Battle of Britain. Its greatest advantage stemmed from the combination of long-range radar data and the streamlined manner in which this information was employed. This information was sent via a high-quality general post office telephone system to filter rooms and then onto sector control rooms to scramble our defending aircraft and inform them of the target's location. The Germans had no idea how we repeatedly managed to position our fighters to fly out of the sun and attack their bomber streams.
Q: What were the limitations of Chain Home radar?
A: One of the biggest limitations was the fact that CH could only provide a fighter with a direction to within one mile - at best - of a target. This was acceptable during clear daylight conditions but not at night or in bad weather. The original CH system's size meant that integration onto an aircraft platform was impossible. The need for a more compact system with greater resolution was quickly recognized, leading to the development of higher-frequency VHF (very high frequency) radars for both airborne and ground applications. Another disadvantage was that the original CH coverage did not go right down to the ground, resulting in approximately 1,000 feet lower operational ceiling where targets could "fly under the radar."
Q: How did the invention of the cavity magnetron alter the way that radar could be used, especially in combat?
A: The long 'metre' wavelengths associated with early radars meant that they could not be miniaturized, nor achieve a greater resolution from compact antennae. The magnetron provided a powerful source of high-frequency energy, enabling the reduction of radar equipment's size and weight and improving range and bearing resolution. This advancement made microwave versions of Air to Surface Vessel (ASV) and Air Intercept radars that could be installed in aircraft, as well as the groundbreaking H2S ground scanning system, possible. Microwave ASV radar could also detect surfaced U-boats, turning the Atlantic U-Boat war in our favor by restricting the U-Boat hunting grounds to a small strip of the Atlantic ocean between Great Britain and the USA. And a post-war spin-off of the magnetron development later resulted in their use in domestic microwave ovens!
