SAO's Chase Light Inappropriately Employed 555 Code, And Lacked Proper Implementation
In the local scene, oversimplified projects that could've employed more straightforward designs are often taunted with the phrase "Should've used a 555," even if the legendary timer chip wouldn't have been the best fit. However, the underlying message rings true - a Frankenstein's monster of a solution is likely one that requires a rethink. And that's exactly what [Johannes] did with his ingenious chaser light badge, aptly named the Simple Add-On (SAO).
Johannes was inspired by the factory automation machines that move parts between levels, each on steps that move out of phase with each other - much like the marble-raising mechanism in [Wintergatan]'s Marble Machine X. So, instead of opting for any random circuit to turn discrete lights on and off, he went the unconventional route, using two thin plates adorned with notches.
Sandwiched between the 3D-printed casing of the SAO, these plates rest between the badge’s face and light source. A small motor and a series of gears rotate these masks 180° out of phase with each other, thus creating the illusion that the light is moving. It's so convincing that initially, we mistook it for a row of tiny LEDs arrayed around the badge's edge.
Bravo to [Johannes] for this crackerjack mechanism! The SAO was just in time for our European website. If you missed out on the talks, fret not! We've prepped a playlist for your viewing pleasure.
