SSR and PSR Principles, Their Benefits, and Limitations:
Let's dive into the world of air traffic control as we explore Primary Surveillance Radar (PSR) and Secondary Surveillance Radar (SSR) systems. These two radar systems play a crucial role in managing aircraft traffic, each with its unique benefits and drawbacks.
First, let's define our terms:
- PSR: Primarily uses reflected radio signals to offer range and bearing data about objects in its coverage area (ICAO Doc 4444 PANS-ATM).
- SSR: Utilizes transmitters/receivers (interrogators) and transponders to provide more detailed and accurate information about aircraft (ICAO Doc 4444 PANS-ATM).
PSR: A Basic Radar System
PSR emits radio waves that bounce off objects in its coverage area and return back to the system. By measuring the time difference between the emitted and received wave pulse, PSR calculates the range, and the bearing is obtained from the antenna azimuth.
SSR: The Enhanced Version
SSR transmits high-frequency pulses called interrogations, which are received by the aircraft's radar transponder. The transponder replies with encoded data like an identity code, the aircraft's altitude, and additional information depending on the chosen mode.
Now, let's check out their pros and cons:
PSR:- No onboard equipment required, reducing potential malfunctions.- A Cone of Silence exists above the antenna, limiting its surveyable area.- Overlapped blips can make it difficult to distinguish between targets at the same slant range.- Limited data may require additional effort for Air Traffic Controllers to correlate the radar blip with the correct aircraft.- Clutter (non-aircraft reflections) can interfere with accurate readings.- Can't obtain target level data.- Range limit issues may prevent detection of targets that are too close to the antenna.
SSR:- Requires less power than PSR.- Immune to clutter, as it relies on onboard equipment for readings.- Needs onboard equipment on aircraft to function, limiting its coverage.- Garbling may result in false or unseen targets due to simultaneous replies.- FRUIT (False Replies Unsynchronized In Time) can create errors in readings.
In conclusion, both PSR and SSR radar systems play vital roles in air traffic control, and understanding their principles, advantages, and limitations helps in making informed decisions for modern air traffic management. To learn more, check out the references below.
