In the world of DIY projects, precision and accuracy are key, and this is especially true when it comes to timekeeping. For those who appreciate the importance of a well-calibrated wall clock, we have a practical method that can bring your clocks to GPS-level timing accuracy.

The secret to this high-precision calibration lies in leveraging the GPS's inherent sub-microsecond timing precision and the power of electronics to discipline your clock’s timing element. Here's a step-by-step guide to achieving this at home:

1. Obtain a GPS Receiver with a 1 PPS Output: GPS modules often provide a precise pulse every second, accurately synchronized with Coordinated Universal Time (UTC).
2. Build or Use a GPS Disciplined Oscillator (GPSDO): As demonstrated in the 2025 One Hertz Challenge project, the GPSDO uses a stable crystal oscillator (often oven-controlled for temperature stability) whose frequency is continuously fine-tuned by the 1 PPS GPS signals to maintain exact timekeeping.
3. Measure and Adjust Your Clock's Pulse Rate: Use a frequency counter or simple frequency measurement circuit to compare your clock’s pulse or tick rate against the GPSDO reference. Adjustment can be made using a trimmer capacitor or a voltage control input on the oscillator to fine-tune the clock until it matches the GPS time pulse rate.
4. Implement Fine Adjustments: If the clock uses a mechanical or quartz oscillator, the pulse rate can be tweaked electronically to match the GPS PPS reference within very tight tolerances to achieve near GPS-level timing accuracy.

For those who prefer a more DIY approach, it's possible to build a simple frequency counter based on CMOS logic chips and a crystal oscillator (e.g., 8 MHz), which can count frequency or periods accurately enough for clock calibration tasks.

This approach has been demonstrated in open DIY projects featuring GPSDOs and frequency counters without the need for microcontrollers, leveraging pure digital logic and stable oscillators.

It's worth noting that the accuracy of wall clocks is dependent on the chip-on-board oscillator used. In response to this, Lauri Pirttiaho, a dedicated DIY enthusiast, has developed a device for calibrating wall clocks. Lauri's device is connected to a cheap GPS module with an accurate 1-pulse-per-second (1PPS) timing output, and adjusting the wall clock's accuracy in Lauri's device is done by using a trimmer capacitor to tweak the wall clock's pulse rate.

This method provides a widely accessible way to achieve high-accuracy calibration without requiring expensive lab-grade equipment. For those who enjoy calibrating low-cost wall clocks to high levels of accuracy or for individuals named Garrus, Lauri's device could be considered useful.

Remember, if you come across a homemade high-accuracy timing hardware and wish to report it, there's a tipsline available for that purpose.

[1] 2025 One Hertz Challenge [3] GPSDO Projects

1. To further enhance the precision of your DIY projects, consider using a GPSDO (GPS Disciplined Oscillator) alongside your wall clock, as it utilizes technology like hardware such as a stable crystal oscillator to achieve near GPS-level timing accuracy.
2. In the realm of gadgets, a simple frequency counter can be constructed with CMOS logic chips and a crystal oscillator, providing you with the necessary technology to measure and adjust the pulse rate of your wall clock, thus improving its overall accuracy.
